Groen AH/1E-80 80-Gallon Gas Kettle – 145,000 BTU

Description

With the ability to hold up to 40 gallons of product, Groen’s AH/1E-80 Gas Kettle uses 145,000 BTU of power to heat, cook, and hold your items. It has a durable stainless steel construction, fully insulated to retain heat and save energy. It heats at up to 58-65% efficiency, is faster than traditional cooking methods, and uses less energy.

Its handy regulating controls, including its automatic shut off/turn on feature, make it easy to maintain proper temperatures consistently, and without constantly watching cooking pots. This AH/1E-80 has a 180 emergy grit interior and its exterior has been polished to a uniform #3 finish. This ensures that your Gas Kettle is both easy to clean and painless to maintain.

Features and Benefits:

• Construction
• 2/3 jacket
• Constructed from solid one-piece 316 stainless steel
• Stainless steel exposed surfaces
• All controls are contained within front control enclosure
• Sheathed in stainless steel kettle body with insulated fiber bar insulation
• Three adjustable legs for leveling
• Faucet mounting bracket comes standard
• Finish
• Interior kettle is polished to a 180 emery grit
• Exterior is polished to a uniform #3 satin finish
• Exter polish ensures maximum ease in cleaning and maintaining appearance
• Drawoff Valve
• 2″ sanitary tangent drawoff made from 316 stainless steel
• Valve has durable insulated handle, rubber compression sealing disk and is easy to disassemble (without tools)
• Drain outlet is equipped with a removable 1/4″ perforated stainless steel strainer
• Cover
• Furnished on 20-gallon units only
• Hinged, dome one-piece unit
• 40-100 gallon capacity units are furnished with a No. 51 counterbalanced actuator designed to maintain the cover in an open or closed position
• Controls
• Regulating thermostat
• Pressure gauge
• Power-ON switch
• Power-ON indicator light
• Heat indicator light
• Low water indicator light
• Water sight gauge
• Pressure safety valve
• Pressure limit control
• Low water cut off
• Gas regulator valve
• Electronic ignition module
• Performance Features
• Thermostatically controlled to automatically shut off when the desired temperature is reached
• Thermostatically controlled to automatically turn on when product temperature drops below the desired setting
• Electronic ignition to standing pilot is standard on all models
• Outsheathinging and fiber insulation retain heat and keep kettle exterior cool to the touch
• Self-Contained Steam Source
• Gas-heated, self-contained steam source to provide kettle temperatures of 150-270°F
• Factory charged with water and rust inhibitor to ensure long life and minimum maintenance

Specifications:

• Model: AH/1E-80
• Capacity: 80-gallons
• Gas Type Must be Specified:
• Natural Gas
• Liquid Propane
• Total BTU: 145,000
• Electrical Information:
• Volts: 115
• Hz: 60
• Phase: Single
• Amps: 5.0
• Installation Information:
• 1/2″ NPT gas line connection
• No remote steam source required
• Warranty Information:
• 1-year parts and labor
• 10-year kettle and body
• Dimensions: 56.5″ H x 48″ W x 56.25″ D
• Approximate Weight: 1,070 lbs.
