Hatco C-15 Compact Booster Water Heater, 208/1, 208/3, 240/1, 240/3, 480/3

Description

This Hatco C-15 Electric Compact Booster Heater with 6 Gallon Storage Capacity is designed to fit next to the dishwasher to provide a final 180°F rinse for dishes, pots and pans, or flatware. With a temperature/pressure relief valve, a pressure reducing valve, and two-temperature/pressure gauges, this Booster Heater is engineered to reduce the risk of over-heating. It has a high-temperature limit control, pilot indicator light, and a low-water cut-off to prevent element burnout due to low water. This C-15 has a fiberglass insulation to maximum heat retention, allowing water to warm faster. Leadtime may vary, please call for details.

Features and Benefits:

• 6-gallon storage capacity
• Electric operation
• Castone® lined tank with a 10-year limited warranty
• Temperature/pressure relief valve
• Pressure reducing valve
• Two temperature/pressure gauges
• High temperature limit control
• Pilot indicator light
• On-off switch
• Low-water cut-off to prevent element burnout due to a low water condition
• Fiberglass insulation to minimize heat loss
• Hatco electric booster heaters are factory pre-plumbed and pre-wired with calibrated immersion thermostat and high temperature limit switch
• Stainless steel front panel and powder-coated silver-gray hammertone body
• Swing-away front panels with low-water cut-off, control fuses and transformer allow quick access to probes and elements for easier serviceability

Different voltage available-Please specify!

Power Information for Single Phase

Power Information for Three Phase

Specifications:

• Model: C-15
• Dimensions (W x D x H*): 13″ x 20.75″ x 19.75″
• Shipping Weight (includes packaging): 120 lbs. (54 kg)
• *Height does not includes legs
• **Includes Temperature/Pressure Relief Valve.
